| Model | RK-1080P-4CH-WIFI | |
| Wireless NVR Specification | ||
| System | Operating System | Embedded Linux OS |
| AV(audio/video)input | Network Video | 4CH |
| Network video input broadbank | 20Mbps | |
| AUdio Bitrate | 64Kbps | |
| AV(audio/video)output | HDMI input | 1920x1080p |
| AV CODEC Specification | Video Resolution | D1/720P |
| synch-playback | 4CH | |
| Video Control | Video/Capture mode | Maual、Time、Motion |
| Playback mode | Real time、Routine、Event | |
| Backup | USB backup | |
| Hard Disk | Type | 1*SATA interface |
| Max Capacity | 4 TB at most for each | |
| External Interface | Network Interface | 1 adaptable RJ45 10M/100M, 1 WIFI interface |
| USB Interface | 2 USB 2.0 | |
| Network Control | Protocol | UPnP (play&plug)/SMTP (email survice)/PPPoE (dial-up) DHCP (Automatically obtain an IP address), etc. |
| Others | Power Supply | DC12V3A |
| Power Consumption (W) | ≤5W(Without HDD) | |
| Operate Temperature (°C) | -10°C~+55°C | |
| Working Humidity (%) RH | 10%~90% | |
| Size | 257mm(W)×210mm(V)×45mm(H) | |
| Weight(excluding HDD) | ≤1Kg | |
| IPC Specification | ||
| Technical Parameters | Sensor | 1/2.8” Sony 222 Progressive Scan Sensor |
| Signal System | PAL/NTSC | |
| Resolution | 1280×720 16 : 9 High Definition | |
| Minimum illumination | Color: 0.1 Lux; B/W: 0.01 Lux | |
| Shutter | 1/25s to 1/25,000s | |
| Lens | 4mm | |
| OSD | Date Time & Title | |
| White Balance | Auto | |
| Day&Night | Auto/Color/BW | |
| 3D-DNR | Auto | |
| Mirror/Flip | On/Off | |
| Frame Specification | Three Streaming at the Same Time: H.264 128×720@30fps or below H.264 640×480@30fps or below | |
| S/N | >39.1 Db | |
| Interface | RJ45/WIFI 802.11b/g/n | |
| General Specification | Anti-thunder Level | Standard IEC61000-4-5 |
| Working Temperature/Humidity | -10°C to+50°C/30% to 80% RH | |
| Working Temperature/Humidity | -20°C to+60°C/20% to 90% RH | |
| Power Input | DC12V-1A | |
| Power consumption | ≤6W | |
| Size | 205(L)×70(W)×55 (H)mm | |
| Weight | 500g | |
| Level of Protection | IP66 | |
